FPC CONN. PITCH 2.54mm ZIF SMT TYPE


Specification :
 Current : 0.5A
 Operating Temperature : -40 ¢XC ~ + 105 ¢XC
 Contact Resistance : 30 Milliionms MAX
 Insulator Resistance : 1000 Megohms Min
 Dielectric Strength : 500 VAC Min
Material :
 Housing : High Temperature Thermoplastic UL94V-0
 Actuator : High temperature Thermoplastic UL94V-0
 Contact : Copper Alloys
 Fitting nail : Copper Alloys
Finish :
 Contact : Tin Plated
 Fitting Nail : Tin Plated
