| Material And Finish : |
| | Insulator : | | Glass-Filled Thermoplastic (PBT) UL94V-0 |
| | Contact : | | Phosphor Bronze Or Bronze |
| | Finishes : | | Tin Plated , Contact Area : Gold Plated |
| Performance Characteristics : |
| | Contact Rating : | | 3 Amperes Continous |
| | Contact Resistance : | | 12 Milliohms Max |
| | Operating Temperature : | | -55 ¢XC to + 105 ¢XC |
| | Voltage Rating (Sea Leve) : | | 1000 Vac |
| | Insulation Resistance : | | 5000 Megohms Min. After Exposure |
| | | | To Humidity |
| | Vibration Tolerance : | | 10 to 500 Hertz |
| | Contact Engagement Force : | | 12.0 Ounces Average |
| | | | Per Pair With .062 (1.57) |
| | | | PC Board |
| | Contact Separation Force : | | 2 Ounces average per pair |
| | | | 0.62 PC board |
| | Humidity Tolerance : | | 90%-95% for 96 Hours |
